    4 Inch Shank SRC004 RC Drill Bit For Mining , Reverse Circulation Drilling

    Ask Lasest Price
    Brand Name : SOLLROC
    Model Number : SRC004 RC bit
    Certification : SGS
    Price : negotiate
    Payment Terms : L/C, D/A, D/P, T/T, , MoneyGram
    Supply Ability : 5000pcs per month
    Delivery Time : 15-22 days
    • Product Details
    • Company Profile

    4 Inch Shank SRC004 RC Drill Bit For Mining , Reverse Circulation Drilling

    4 Inch Shank SRC004 RC Drill Bit For Mining , Reverse Circulation Drilling


    Product Introduce:

    Reverse Circulation drilling, or RC drilling, is a method of drilling which uses dual wall drill rods that consist of an outer drill rod with an inner tube. These hollow inner tubes allow the drill cuttings to be transported back to the surface in a continuous, steady flow.Reverse circulation. The course of drilling fluid downward through the annulus and upward through the drill stem, in contrast to normal circulation in which the course is downward through the drill stem and upward through the annulus. Seldom used in open hole, but frequently used in workover operations.


    Adavantages:

    A higher percentage of uncontaminated cuttings

    Drilling rate similar to open hole drilling, but can often be faster and penetrate greater depths

    One of the most accurate drilling methods

    Quick retrieval of sample rates

    Dry samples allow for easier analysis


    Woring Principle:

    By using compressed air to extract rock fragments sample,the samples travel through rods to a sample splitter at surface, avoiding all contact between the samples and the borehole wall that allows samples to be retrieved with minimal contamination.


    Specification:

    SOLLROC RC BIT model SRC004

    Diameter

    Buttons * button diameter

    Button angle

    Flushing holes

    Shroud diameter (mm)

    weight (kg)

    mm

    inch

    Gauge

    Centre

    114

    4 1/2

    8*14mm

    8*13mm

    35

    2

    112

    11.8

    118

    4 5/8

    8*14mm

    8*13mm

    35

    2

    116

    12

    1214 3/48*14mm8*13mm35211912.4
    12758*14mm8*14mm35212512.8


    About us:

    SOLLROC Reverse Circulation drilling (RC) ,from size 3’’ to 5.5’’, is a technique of drilling that uses dual wall drill rods that consist of an outer drill rod with an inner tube. By using compressed air to extract rock fragments sample,the samples travel through rods to a sample splitter at surface, avoiding all contact between the samples and the borehole wall that allows samples to be retrieved with minimal contamination,which is mainly used in deep hole exploration and mining grade control.


    Delivery Way:

    By Air, By express or By Sea


    Package :

    Ply-wooden cases + pallet
